Zone Tang Container House Product Description |
Expandable container house is a type of container house, we also call it the double-wing folding house, which has a striking innovative residential design and has attracted much attention due to their unique form and flexible functions.
Expandable container house adopts a double-wing structure, looks like a bird spreading its wings, the best advantage is that the wings can be extended when it is necessary to expand, creating greater comfort and freedom in daily life.
It can be used for temporary dormitories and offices, tourism, car camps, exhibition halls, hotels, schools, shops and so on.
Expandable container house emphasizes the concepts of environmental protection and sustainable development. Adopting energy-saving materials and designs, optimizing indoor lighting and ventilation systems to minimize energy waste.
More importantly, customers can customize the house according to their preferences, the size, color, materials of the house can be selected, and installation is simple.
Certification | CE, ISO |
Color | Customized |
Customized | Available |
Life Span | >20years |
Trademark | Zone Tang |
Internal Size(mm) | Based on the thickness of wall panels / roof beam / bottom beam |
Shipping | 40FTshipping container can load 2 sets |
Main material | Galvanized steel structure with sandwich panel wall and doors, windows, etc. |
Origin | Shandong,China |
Design Style | Modern and Customized |
MOQ | 1 |
Columns | Galvanized steel structure(or hot galvanized) |
Service | Video technology, Online and Site Support |
Warranty | 1 year |
External Size | 20ft: L5900*W6300* H2480 30ft: L9000*W6220* H2480 40ft: L11800*W6240* H2480 or customized |
Roof | Ceiling tile 50mm EPS sandwich panel |
Weight | 1800kg-5000KG |
Frame | Hinge Galvanized 50.8mm*30mm*1mm |
Hinge Galvanized 100mm*60mm*1mm | |
Hinge Galvanized 63mm*35mm*1mm | |
Hinge Galvanized 101.6mm*76.2mm9*2mm | |
Hinge Galvanized 88.9mm*88.9mm*3mm | |
Top purline 80*100/140*1.5mm | |
Bottom purline 40*80*1.5mm | |
Floor | Middle room floor 1/1.5/1.8/2 mm plastic flooring or floor leather or laminated wood floor or patterned aluminum sheet |
Side rooms floor 1/1.5/1.8/2 mm plastic flooring or floor leather or laminated wood floor or patterned aluminum sheet | |
Kitchen | High-density particle board kitchen cabinet with sink or customized(quoted separately) |
Electrical system | Match local standard & other country electrical standards, wire essential; Other electrical supplies are optional and quoted separately ( available distribution box, lights, switch, sockets, air conditioning socket or customized) |
Door | Steel security door , Plastic-steel door, Aluminum door, Fireproof door, KFC door or Customized |
window | Broken bridge aluminum, aluminium alloy frame, Color steel sliding window or Customized |
Wall Panel | Roof insulation 50mm/75mm EPS sandwich panel |
wall panel 50mm/75mm EPS sandwich panel | |
Inside wall 50mm EPS sandwich panel | |
optional accessories | Furniture, bathroom, shower, ceiling, decorative materials, etc. |
Production Capacity | 500 set/Month |
Application | office,toilet,bathroom,changing room,school,classroom,library,shop, meeting room,canteen,guard house, camp dormitory, camp hotel, playground castle, resort area, earthquake relief materials, post-war reconstruction materials etc, |
Package | Suitable for sea transport, waterproof packaging |
Sewerage system | Water supply pipeline: PPR material Drainage pipeline: PVC material |
Waterproof Performance | A |
Thermal Insulating | A |
Surface | Galvanizing+Painting |
Advantage | 1)fast installation:5hours/set/person,save labor cost; |
2)Anti-rust:all materiel can use galvanized steel | |
3)waterproof: steel ceiling,wall,floor | |
4)fireproof:Fire rating A grade | |
Service support | 1)Make design for clients |
2)Provide pictures and production schedule for clients every 3 days | |
3)provide packing list and installation instruction for clients before shipping | |
4)Can sent installation engineer to clients site for installation instruction | |
Price terms | FOB, CIF ,CFR |
Port | Qingdao or Tianjin |
Delivery time | According to the quantity and type of products, we will delivery within 3 days to 1 month after receipt of payment. |
Terms of Payment | TT; L/C |
Zone Tang Container House Advantage |
1)Expandable container house has good mobility and adaptability, it can be quickly assembled and disassembled, making it easy to relocate to different locations.
2)Safety, comfort, environmental protection and energy saving, easy installation and customization.
3)Expandable Container House is made of high-quality steel, galvanized and painted to ensure a long service life under wet and rainy conditions.
4)Sturdy and durable, all made of steel, with strong resistance to earthquakes and deformation.
5)It can achieve seismic level 8, wind resistance level 10, fire safety level A, and also has the comfortable performance of large space, breath ability, sound insulation and heat preservation.
6)Good sealing performance, the strict manufacturing process makes this container house has good water tightness.
7)High quality, using high quality raw materials
Zone Tang Container House Service support |
1)Make design for clients
2)Provide pictures and production schedule for clients every 3 days
3)provide packing list and installation instruction for clients before shipping
4)Can sent installation engineer to clients site for installation instruction
5)Prices, our prices are set according to the materials used in each customized house
6)Quality, our quality in the corresponding price will be the best quality
7)Design, we have a special design team, for each customer to design a satisfactory expandable house, we will also be in accordance with the needs of each customer to make customers satisfied with the expandable house
8)Service,Any question.welcome to contact us.24 hours available for you One order,one special person to follow the whole production.For the house install,we will give you the 3D install drawing.
Zone Tang Container House Product category |
Flat pack container hosue | Expandable container house | |
Folding container house | Space capsule house | |
Creative container house | Apple capsule house | |
Prefab house | Light steel villa |
Zone Tang Container House Case Show |
Single width Container Home | Expandable Container-House | |
Expandable Container House | Expandable Container House | |
Flat Pack house | Installation of single width container houses |
Zone Tang Container House Processing workshop display |
Processing Workshop | Processing Workshop | Processing Workshop | ||
Processing Workshop | Processing Workshop | Processing Workshop |
Zone Tang Container House Company Profile |
Zone Tang Steel Structure Limited is a specialized enterprise dedicated to the research and development, production, and sales of high-quality steel structures, mobile home and container engineering construction.
Our company is located in Weifang City, known as the kite capital of the world, with convenient transportation due to its ocean shipping. we have 16 years professional experience, and our plant spanning across 10,000 square meters.
Our products including flat pack house, expandable container house, folding container house, modified shipping container house, functional container house, prefab house, mobile house, prefab villa, space capsule house etc...All are made of prefabricated steel structures, and each product can be customized according to customer's needs.
"Quality from Professionalism,Professionalism creates Quality",Zone Tang has always adhered to the five basic principles of " first-class technology, first-class quality, first-class speed, first-class management and first-class service," aiming to provide high-quality projects for domestic and foreign customers while also showcasing Chinese manufacturing power and aesthetics to global friends.
